Yokes and Rigs

   131 products found.
Swivel Caster Yoke with a treaded stem and pedal total locking brake.
Yoke; Swivel; 5" x 1-1/4"; Threaded Stem (1/2"-13TPI x 1-1/2"); Zinc; 3/8" Bore; 1-9/16" Hub Length; 300#; Total Lock (Mtl) (89057)
Item: 89057
Only: $12.21
Yoke; Swivel; 5" x 1-1/4"; Threaded Stem (1/2"-13TPI x 1-1/2"); Zinc; 3/8" Bore; 1-9/16" Hub Length; 300#; Total Lock (Mtl)
Overall Height: 5-1/4"
Weight Cap: 300 lbs.

Swivel Caster Yoke with hollow kingpin.
Yoke; Swivel; 6" x 2"; Hollow Kingpin (1/2" bolt hole); Zinc; 1/2" Bore; 2-7/16" Hub Length; 400# (#89618 is the axle bolt/ nut) (88368)
Item: 88368
Only: $7.99
Yoke; Swivel; 6" x 2"; Hollow Kingpin (1/2" bolt hole); Zinc; 1/2" Bore; 2-7/16" Hub Length; 400# (#89618 is the axle bolt/ nut)
Overall Height: 7-3/8"
Weight Cap: 400 lbs.

Replacement Caster Yoke, Axle and Nut
Yoke & Axle; Rigid; 4" x 1-1/4"; Plate (2-3/8"x3-5/8"; holes: 1-3/4"x2-7/8" slotted to 3"; 5/16" bolt); Stainless Steel; 3/8" Bore; 1-9/16" Hub Length; 350# (88350)
Item: 88350
Only: $15.22
Yoke & Axle; Rigid; 4" x 1-1/4"; Plate (2-3/8"x3-5/8"; holes: 1-3/4"x2-7/8" slotted to 3"; 5/16" bolt); Stainless Steel; 3/8" Bore; 1-9/16" Hub Length; 350#
Overall Height: 5-1/8"
Weight Cap: 350 lbs.

Replacement Caster Yoke
Yoke; Swivel; 6" x 2"; Top Plate (4"x4-1/2"; holes: 2-5/8"x3-5/8" slotted to 3"x3"; 3/8" bolt); Zinc; 1/2" Bore; 2-1/2" Hub Length; 1250#; Total Lock (Leading) (88832)
Item: 88832
Only: $18.54
Yoke; Swivel; 6" x 2"; Top Plate (4"x4-1/2"; holes: 2-5/8"x3-5/8" slotted to 3"x3"; 3/8" bolt); Zinc; 1/2" Bore; 2-1/2" Hub Length; 1250#; Total Lock (Leading)
Overall Height: 7-1/2"
Weight Cap: 1250 lbs.

Replacement rigid Caster Yoke.
Yoke; Rigid; 4" x 2"; Top Plate; 4"x4-1/2"; hole spacing: 2-5/8"x3-5/8" (slotted to 3x3); 3/8 bolt; Zinc; 1250#; 1/2 axle bore (89528)
Item: 89528
Only: $4.71
Yoke; Rigid; 4" x 2"; Top Plate; 4"x4-1/2"; hole spacing: 2-5/8"x3-5/8" (slotted to 3x3); 3/8 bolt; Zinc; 1250#; 1/2 axle bore
Overall Height: 5-5/8"
Weight Cap: 1250 lbs.

Replacement Caster Yoke
Yoke; Swivel; 6" x 2"; Plate (4"x4-1/2"; holes: 2-5/8"x3-5/8" slotted to 3"x3"; 3/8" bolt); Zinc; 1/2" Bore; 2-1/2" Hub Length; 1250#; Position Lock (4-way) (88833)
Item: 88833
Only: $11.10
Yoke; Swivel; 6" x 2"; Plate (4"x4-1/2"; holes: 2-5/8"x3-5/8" slotted to 3"x3"; 3/8" bolt); Zinc; 1/2" Bore; 2-1/2" Hub Length; 1250#; Position Lock (4-way)
Overall Height: 7-1/2"
Weight Cap: 1250 lbs.

Replacement Caster Yoke, Axle and Nut
Yoke, Axle & Nut; Swivel; 3" x 1"; Threaded Stem (7/16"-14TPI x 2-1/4"); Zinc; 5/16" Bore; 1-5/16" Hub Length; 150# (88502)
Item: 88502
Only: $4.35
Yoke, Axle & Nut; Swivel; 3" x 1"; Threaded Stem (7/16"-14TPI x 2-1/4"); Zinc; 5/16" Bore; 1-5/16" Hub Length; 150#
Overall Height: 3-3/4"
Weight Cap: 150 lbs.

Replacement Caster Yoke
Yoke; Swivel; 4" x 2"; Plate (4"x4-1/2"; holes: 2-5/8"x3-5/8" slotted to 3"x3"; 3/8" bolt); 1/2" Bore; 1250#; Leading Total Lock . Fits most 4x2 wheels. (88829)
Item: 88829
Only: $18.20
Yoke; Swivel; 4" x 2"; Plate (4"x4-1/2"; holes: 2-5/8"x3-5/8" slotted to 3"x3"; 3/8" bolt); 1/2" Bore; 1250#; Leading Total Lock . Fits most 4x2 wheels.
Overall Height: 5-5/8"
Weight Cap: 1250 lbs.

Swivel Caster Yoke
Yoke; Swivel; 5" x 1-1/4"; Top Plate (2-5/8"x3-3/4"; holes: 1-3/4"x2-3/4" slotted to 3"; 5/16" bolt); Zinc; 3/8" Bore; 325#; Dust Cover (Mtl) (89012)
Item: 89012
Only: $6.57
Yoke; Swivel; 5" x 1-1/4"; Top Plate (2-5/8"x3-3/4"; holes: 1-3/4"x2-3/4" slotted to 3"; 5/16" bolt); Zinc; 3/8" Bore; 325#; Dust Cover (Mtl)
Overall Height: 6-1/4"
Weight Cap: 325 lbs.

Swivel Caster Yoke
Yoke & Axle; Swivel; 6" x 2"; Top Plate (4-1/2"x6-1/4"; holes: 2-7/16"x4-15/16" slotted to 3-3/8"x5-1/4"; 1/2" bolt); Zinc; 1/2" Bore; 2-7/16" Hub Length; 1250# (88020)
Item: 88020
Only: $14.10
Yoke & Axle; Swivel; 6" x 2"; Top Plate (4-1/2"x6-1/4"; holes: 2-7/16"x4-15/16" slotted to 3-3/8"x5-1/4"; 1/2" bolt); Zinc; 1/2" Bore; 2-7/16" Hub Length; 1250#
Overall Height: 7-1/2"
Weight Cap: 1250 lbs.

Replacement Caster Yoke, Axle and Nut
Yoke Axle & Nut; Swivel; 3" x 1-1/4"; Threaded Stem (1/2"-13TPI x 2-9/16"); Zinc; 3/8" Bore; 1-9/16" Hub Length; 300# (88413)
Item: 88413
Only: $6.20
Yoke Axle & Nut; Swivel; 3" x 1-1/4"; Threaded Stem (1/2"-13TPI x 2-9/16"); Zinc; 3/8" Bore; 1-9/16" Hub Length; 300#
Overall Height: 4-1/16"
Weight Cap: 300 lbs.

Replacement Caster Yoke, Axle and Nut
Yoke; Swivel; 3" x 1-1/4"; Plate (2-3/8"x3-5/8"; holes: 1-3/4"x2-7/8" slotted to 3"; 5/16" bolt); Zinc; 3/8" Bore; 1-9/16" Hub Length; 300#; Dust Cover (Mtl) (88512)
Item: 88512
Only: $6.84
Yoke; Swivel; 3" x 1-1/4"; Plate (2-3/8"x3-5/8"; holes: 1-3/4"x2-7/8" slotted to 3"; 5/16" bolt); Zinc; 3/8" Bore; 1-9/16" Hub Length; 300#; Dust Cover (Mtl)
Overall Height: 4"
Weight Cap: 300 lbs.

Swivel caster with threaded stem, blue polyu wheel and bearing cover.
Shopping Cart Swivel Yoke; 5" x 1-1/4"; Threaded Stem (1/2"-13TPI x1") With Keylock; Zinc; 5/16" Bore; 1-5/8" Hub Length; 250#; Raceway Seal, Axle included. (88489)
Item: 88489
Only: $6.43
Shopping Cart Swivel Yoke; 5" x 1-1/4"; Threaded Stem (1/2"-13TPI x1") With Keylock; Zinc; 5/16" Bore; 1-5/8" Hub Length; 250#; Raceway Seal, Axle included.
Overall Height: 5-7/8"
Weight Cap: 250 lbs.

Replacement Caster Yoke with a kingpinless raceway.
Yoke; Swivel; 6" x 2"; Plate (4"x4-1/2"; holes: 2-5/8"x3-5/8" slotted to 3"x3"; 3/8" bolt); Zinc; 2000#; 1/2 bore; 2-1/2" Hub Length; Kingpinless (88517)
Item: 88517
Only: $29.15
Yoke; Swivel; 6" x 2"; Plate (4"x4-1/2"; holes: 2-5/8"x3-5/8" slotted to 3"x3"; 3/8" bolt); Zinc; 2000#; 1/2 bore; 2-1/2" Hub Length; Kingpinless
Overall Height: 7-1/2"
Weight Cap: 2000 lbs.

Replacement Caster Yoke, Axle and Nut
Yoke, Axle & Nut; Swivel; 4" x 1"; Grip Ring (7/16" x 1-1/2"); Zinc; 5/16" Bore; 1-3/16" Hub Length; 230# (88623)
Item: 88623
Only: $3.33
Yoke, Axle & Nut; Swivel; 4" x 1"; Grip Ring (7/16" x 1-1/2"); Zinc; 5/16" Bore; 1-3/16" Hub Length; 230#
Overall Height: 4-3/4"
Weight Cap: 230 lbs.
